This archive contains a collection of documents and images of interest to pilot and aviation enthusiast.

Documents And Forms

TB-10 Checklist. Copyright © 2001. A condensed one page version of the checklist items for a Socata Tobago (TB-10) airplane. Can be folded to make a half-sheet, double-sided card that is an ideal size to fit in a pilot's knee-board.
VFR Flight Planning Log. Copyright © 2001. An improved flight planning log form for Visual Flight Rules (VFR) flights.
IFR Flight Planning Log Form. Copyright © 2001. An improved flight planning log form for Instrument Flight Rules (IFR) flights.
Weather Symbols Reference Chart. A complete visual reference of all NOAA weather symbols used on weather maps for aviation briefings.

Aircraft Cockpits

Click on any image to view the full size image in a new browser window or tab. Right click on any image and choose "Save Target As..." to save a copy of the image.

Piper Warrior (PA28-161) c. 1974

Piper Warrior II (PA28-161) c. 1982

Socata Tobago (TB-10) c. 1986

Cessna 152 (C-152) c. 2012

Boeing 747 (B747)

Boeing 727 (B727)

Boeing 737 (B737)

Boeing 777 (B777)

Boeing 787 Dreamliner (B787)

Airbus A-319 (A319)

Airbus A-350 (A350)

Embraer 145 Regional Jet (ERJ-145)

Cessna 1000 Regional Jet (CRJ-1000)

Honda Business Jet

Space Shuttle Atlantis

Some Notes About Cockpit Picture, Row 1, Column 3 (from left)
Socata Tobago (TB-10), Serial Number 606, c. 1986

Picture taken in 2009. Extensive avionics upgrades. Notably, this aircraft is the first TB-10 in the U.S. outfitted with a JPI EDM 930 glass display engine management system (EMS). Also noteworthy is the Mode S transponder with traffic avoidance system, integrated with the Garmin GNS-430 GPS Receiver, and the integrated GNSS/S-TEC autopilot system.
